Raspberry Pi4 on xrdp has screen tearing or distortion

January 10, 2024 · 2 min read

I use my Raspberry Pi4 as a home media server with Plex using Ubuntu Desktop. I use a large flash drive for content that needs me to login every time the machine reboots. I started running into a consistent issue where every login would be met with distortion that looked something like:

xrdp distortion on Raspberry Pi4

I had a difficult time searching for just what this could be and took a few different approaches that worked with mixed results:

  1. Installed a different window manager like xfce4 or kde-plasma

    1. This worked for a minute until it stopped. I have no clue what magic I did at first but I oddly prefer Gnome now.
  2. Created a new user.

    1. I'm not using the default user to begin with but my user jeremy was the only one on the system.
    2. This worked perfectly but it meant setting quite a bit up under the second user.
    3. I absolutely do not understand what in a new user is different to make this one option work consistently.
    4. See https://www.reddit.com/r/raspberry_pi/comments/qw1cdw/comment/huqutq1/?utm_source=share&utm_medium=ios_app&utm_name=iossmf&context=3
    5. See https://www.reddit.com/r/raspberry_pi/comments/176cz2u/raspberry_bookworm_xrdp_gpu_acceleration_issue/
  3. The approaches outlined in https://devicetests.com/fixing-xrdp-black-screen-issue-ubuntu including the installation script.

    1. I made some of these tweaks before as I had the blackscreen problem and I bit the bullet to reinstall xrdp on a whim.
    2. The updated installation script can be found at https://www.c-nergy.be/products.html.
    3. This did nothing and now I'm greeted with self-sign cert warnings every time I connect.

The solution I ended up going with was outlined in https://forums.raspberrypi.com/viewtopic.php?t=358088 as it works flawlessly for my current user, just as it was before whatever recent update broke it.

sudo nano /etc/X11/xrdp/xorg.conf

Find the line Option DRMDevice line and change it to

Option "DRMDevice" ""

reboot raspberry pi

This is one of the reasons I am not a fan of Linux on the desktop, even in 2024 nor do I think it passes the "grandma test." It was damn near impossible to search for this reliably and took me multiple days of searching over a few weeks. Grandma may have that kinda time because she's retired but I'm not, I need the shit to just work(tm). The Linux desktop experience has come a really long way from when I started working with it though.

Diagnosing direnv issues using rtx

January 4, 2024 · 2 min read

I returned to a somewhat older Phoenix v1.6 application I had written that utilized direnv to load environment variables from a .env file. Coming from Laravel, I'm highly used to this workflow and I found that using something like direnv to inject the variables was better than the hacks I had been using at the time.

I started using asdf as a version-manager-of-all-trades before moving over to rtx. I liked its ergonomics and I had yet to run into an issue where I thought asdf was a better choice until now. The issue I was having was that for whatever reason direnv wasn't executing upon entering the directory as I had been used to.

Running direnv status showed output similar to the following:

direnv exec path /Users/jbrayton/.local/share/rtx/installs/direnv/2.32.2/bin/direnv
DIRENV_CONFIG /Users/jbrayton/.config/direnv
bash_path /usr/local/bin/bash
disable_stdin false
warn_timeout 5s
whitelist.prefix []
whitelist.exact map[]
No .envrc or .env loaded

There was more included but the key to focus on was No .envrc or .env loaded.

I ran through a couple of steps to try to figure out what was going on. I had found on their website that for the fish shell that I likely needed to wire up the direnv hook fish | source into my generic ~/.config/fish/config.fish file. To do that I installed direnv via homebrew because previously using it with rtx meant even my global usage wasn't global, or I was holding it wrong(tm).

What I was unaware of at the time was that when I went to update rtx I saw that homebrew changed the name to mise but the command mise wasn't found. After running brew install mise I was able to see the following migration output:

migrating /Users/jbrayton/.local/share/rtx/installs/elixir to /Users/jbrayton/.local/share/mise/installs
migrated rtx directories to mise
see https://mise.jdx.dev/rtx.html
migrating /Users/jbrayton/.config/rtx to /Users/jbrayton/.config/mise
migrated rtx directories to mise
see https://mise.jdx.dev/rtx.html

I'm making this post primarily for my own benefit though I seriously doubt I would ever run into this again on this machine or another. It's possible someone else may see similar weirdness with either one of the rtx plugins or something similar. From my understanding of all my other projects, rtx was working flawlessly except for this one instance but it turned out that direnv was broken for my entire system. The other projects that used it weren't working either.

If you see some weirdness with rtx and you haven't migrated, performing the migration may help you move forward like it did for me.

It's also worth noting that the migration doesn't copy your installs and I have 10GB of data in my old installs directory that I'll need to prune.

Diagnosing Nginx errors on PHP 8.2

November 17, 2023 · 3 min read

Upon testing some new functionality locally, I noticed that I was getting my favorite error, 502 Bad Gateway.

I had a look at the error logs in ~/.config/valet/Log/nginx-error.log and found this grouping of errors:

2023/11/17 13:42:09 [error] 89485#0: *1 connect() to unix:/Users/jbrayton/.config/valet/valet.sock failed (61: Connection refused) while connecting to upstream, client: 127.0.0.1, server: stripe-sync.test, request: "GET / HTTP/2.0", upstream: "fastcgi://unix:/Users/jbrayton/.config/valet/valet.sock:", host: "stripe-sync.test"
2023/11/17 13:43:21 [error] 89483#0: *12 connect() to unix:/Users/jbrayton/.config/valet/valet.sock failed (61: Connection refused) while connecting to upstream, client: 127.0.0.1, server: stripe-sync.test, request: "GET / HTTP/2.0", upstream: "fastcgi://unix:/Users/jbrayton/.config/valet/valet.sock:", host: "stripe-sync.test"
2023/11/17 13:45:54 [error] 89476#0: *44 connect() to unix:/Users/jbrayton/.config/valet/valet.sock failed (61: Connection refused) while connecting to upstream, client: 127.0.0.1, server: stripe-sync.test, request: "GET / HTTP/2.0", upstream: "fastcgi://unix:/Users/jbrayton/.config/valet/valet.sock:", host: "stripe-sync.test"
2023/11/17 13:51:39 [error] 89471#0: *49 connect() to unix:/Users/jbrayton/.config/valet/valet.sock failed (61: Connection refused) while connecting to upstream, client: 127.0.0.1, server: larajobs-menubar.test, request: "GET / HTTP/2.0", upstream: "fastcgi://unix:/Users/jbrayton/.config/valet/valet.sock:", host: "larajobs-menubar.test"

I performed a generic Google search for nginx "*12 connect()" to unix Nothing hit me directly but it did highlight the excellent primer on Datadog NGINX 502 Bad Gateway: PHP-FPM I ran valet links to get a list of other sites to try to see if this was isolated to a PHP version and it was, PHP 8.2 was the only one having problems. I had tried valet restart and valet restart php but that didn't help. I wanted to check the status of services to make sure they were running and we can do that via valet status:

Checking status...

Valet status: Error

+--------------------------------------+----------+
| Check                                | Success? |
+--------------------------------------+----------+
| Is Valet fully installed?            | Yes      |
| Is Valet config valid?               | Yes      |
| Is Homebrew installed?               | Yes      |
| Is DnsMasq installed?                | Yes      |
| Is Dnsmasq running?                  | Yes      |
| Is Dnsmasq running as root?          | Yes      |
| Is Nginx installed?                  | Yes      |
| Is Nginx running?                    | Yes      |
| Is Nginx running as root?            | Yes      |
| Is PHP installed?                    | Yes      |
| Is linked PHP (php) running?         | No       |
| Is linked PHP (php) running as root? | No       |
| Is valet.sock present?               | Yes      |
+--------------------------------------+----------+

Debug suggestions:
Run `valet restart`.
Uninstall PHP with Brew and run `valet use php@8.2`

I ended up using valet use php@8.2 --force in the end:

⋊> brew uninstall php
Error: Refusing to uninstall /usr/local/Cellar/php/8.2.11
because it is required by composer, php-cs-fixer and wp-cli, which are currently installed.
You can override this and force removal with:
  brew uninstall --ignore-dependencies php
⋊> valet use php@8.2
Valet is already using version: php@8.2. To re-link and re-configure use the --force parameter.

⋊> valet use php@8.2 --force
Unlinking current version: php
Linking new version: php@8.2
Stopping phpfpm...
Stopping php@7.2...
Stopping php@8.1...
Installing and configuring phpfpm...
Updating PHP configuration for php@8.2...
Restarting php@8.1...
Restarting php@7.1...
Restarting php@7.4...
Restarting php@7.2...
Restarting php@7.3...
Restarting php...
Restarting nginx...
Valet is now using php@8.2.

Note that you might need to run composer global update if your PHP version change affects the dependencies of global packages required by Composer.

The stop messages not aligning with the restarts is particularly interesting and likely part of what I was dealing with. I hadn't tried sites tied to each version independently.

Livebook Tweaks

July 1, 2023 · 4 min read

I've learned a few things using Livebook that took a minute to uncover, so I wanted a place to keep it all together. I'll list them as a table of contents and explain further in each section, with links to my stumbling through issues and PRs.

  1. Version management: if you use a version manager like asdf or rtx, the Livebook version will be bound to your global or local instance, depending on the directory.
  2. MacOS app bundles Elixir: the Livebook desktop app is a great case study for bundling Erlang and Elixir.
  3. Reopening Livebook: if you close the Livebook window, you can open a new one by clicking on the Menu Bar icon and selecting Open.
  4. Menu Bar quirks: when running applications like Vanilla or Bartender, the icon only shows up if I restart Vanilla.
  5. Remote file management: the docker image defaults the working directory to /data, so if you use relative pathing in your notebooks or apps for storing files, you either have to infer this or change the WORKDIR in Docker.

Version Management

I spent maybe 20-30 minutes installing Livebook 0.9.3 and running it for my collection of notebooks. I would execute the command livebook server index.livemd in the directory, which ran version 1.14.4 at the time of discovery. When I upgraded Livebook, I was outside this directory which took in the global version 1.14.5. Because rtx or asdf completely isolates versions, I wasn't aware it was executing the 0.9.2 build with 1.14.4. Changing .tool-versions by using rtx use elixir@1.14.5-otp-25 brought my local environment up to global, and the Livebook version was what I expected.

I suspect this may bite me and others consistently if we're not careful. I'm sure I've had similar issues in the past that I did not equate to this at the time.

Desktop Elixir Bundler

A ton has changed since January 2022, but I opened this issue, which spurred a subsequent pull request. This work has slowly morphed into what is being called "ElixirKit" and is in the elixirkit/ directory in the repository. ElixirKit has a different surface area than Elixir Desktop, which is somewhat of a wrapper or orchestrator for wxWidgets in Elixir.

Reopening Livebook

In the past, when this was a Dock icon only, if you closed the browser window, it was less intuitive for me to open it again. I could reopen the window by clicking the Dock icon (see this issue for history). Now the app stays resident in the Menu Bar, and we can reopen windows or view logs to see the hidden console window. The view logs option is perfect for getting the auth token again. The dock also had issues fully closing the runtime but was ironed out <3.

I use the free version of the Vanilla app. If Livebook is on the always-visible right side, the icon will display whenever I close and reopen the desktop app. If it's on the default left side, I must quit Vanilla for the icon to appear. The long-term fix of keeping it visible is enough for me, but it may bite other people that use similar menu bar applications.

This issue spells out what I saw and may be helpful. I kept trying to run the app again, not knowing that it was there in the menu bar but I just couldn't see it.

Remote File Management

I had issues understanding how to work with notebooks or public apps on Huggingface. When I used something like data = "./data/file-sorted.csv" where the notebook-relative data/ directory existed, I would get problems like ** (File.Error) could not open "./data/file-sorted.csv": no such file or directory. My fix at the time was for apps to use something like data = System.get_env("PWD") to get the current working directory. This change posed a problem locally because my relative data/ directory is in .gitignore. Using PWD would save the data in the current directory, which would not fall under .gitignore rules.

The long-term fix, which you can see here, was to include WORKDIR "/notebooks" at the end of the file. WORKDIR tells Docker the working directory so that /data is now the place for only Livebook configuration, and any relative paths will work as expected.

There are other parts to this Dockerfile, such as pulling down my notebooks and the ash_tutorial so that I could work on Huggingface for things like Whisper or other ML models. Adding git or FFmpeg as dependencies is trivial. I explicitly copy the public-apps directory from my repository so that the Huggingface repo stays pure and only cares about setting up the environment.

One of my goals is to flesh out a system where I can work on notebooks remotely and periodically synchronize changes up to the repository. That's why I've included git-sync but I haven't worked out how to leverage it. A public or private app could leverage Kino.start_child/1 to start a GenServer that watches the filesystem for changes and presents a UI to commit and push changes. I believe something like egit could do this, I would need to create the UI for it. I'd certainly take this approach over shelling out to the git CLI though that's not extraordinarily difficult either.

Running Keycloak with Postgres in Docker

April 2, 2023 · 3 min read

I was recently tasked with evaluating Laravel-based and external SSO workflows and stumbled on Keycloak in several places. There is a Socialite provider as well as Supabase auth so I needed a way to make a quick evaluation. I chose to use Docker as I didn't want to dive into the world of Java installations. There is some extensive documentation, but like some OSS projects, it can be a firehose at times.

Fortunately, Google came to the rescue with many resources I've included at the bottom of this post for reference. A Docker compose file to spin up the Keycloak container and Postgres to store its data. The docker image needs environment variables set and the best way I know to do that is through direnv and specifically the asdf version manager plugin for it.

docker-compose.yml

I lifted this template from this StackOverflow post and surgically altered it for my purposes. I commented out the parts that weren't relevant and stripped away the backend and frontend services since I no longer needed them.

---
version: "3.8"

services:
  database:
    image: postgres:14
    container_name: database
    environment:
    # add multiple schemas
      # POSTGRES_MULTIPLE_DATABASES: ${DB_DATABASE},${KEYCLOAK_DATABASE}
      POSTGRES_DB: ${DB_DATABASE}
      POSTGRES_USER: ${DB_USER}
      POSTGRES_PASSWORD: ${DB_PASSWORD}
      # POSTGRES_KEYCLOAK_USER: ${KEYCLOAK_USER}
      # POSTGRES_KEYCLOAK_PASSWORD: ${KEYCLOAK_PASSWORD}
      # POSTGRES_DB2: ${KEYCLOAK_DATABASE}
    hostname: local
    restart: always
    volumes:
      - ./db-data:/var/lib/postgresql/data/
      - ./sql:/docker-entrypoint-initdb.d/:ro
      # - ./sql/access_attempt.sql:/docker-entrypoint-initdb.d/A.sql
      # - ./sql/bceid.sql:/docker-entrypoint-initdb.d/B.sql
      # - ./sql/lookup_activitytype.sql:/docker-entrypoint-initdb.d/C.sql
      # - ./sql/lookup_gender_pronoun.sql:/docker-entrypoint-initdb.d/D.sql
      # - ./sql/client.sql:/docker-entrypoint-initdb.d/E.sql
    ports:
      - "5439:5432"
    networks:
      - db-keycloak

  keycloak:
    image: quay.io/keycloak/keycloak:21.0.1
    command: ["start-dev"]
    container_name: keycloak
    environment:
      DB_VENDOR: ${DB_VENDOR}
      DB_ADDR: database
      DB_PORT: 5432
      DB_SCHEMA: public
      DB_DATABASE: ${DB_DATABASE}
      DB_USER: ${DB_USER}
      DB_PASSWORD: ${DB_PASSWORD}
      KEYCLOAK_USER: ${KEYCLOAK_USER}
      KEYCLOAK_PASSWORD: ${KEYCLOAK_PASSWORD}
      KEYCLOAK_ADMIN: ${KEYCLOAK_ADMIN}
      KEYCLOAK_ADMIN_PASSWORD: ${KEYCLOAK_ADMIN_PASSWORD}
      KC_PROXY_MODE: edge
      KC_METRICS_ENABLED: true
      KC_HTTP_ENABLED: true
    ports:
      - "8089:8080"
      - "8443:8443"
    depends_on:
      - database
    restart: always
    links:
      - database
    networks:
      - db-keycloak

networks:
  db-keycloak:
    driver: bridge

.env

This sets the environment variables used by both Postgres and Keycloak.

APP_DOMAIN="localhost"
DB_VENDOR="postgres"
DB_DATABASE="keycloak"
DB_USER="keycloak"
DB_PASSWORD="keycloak"
KEYCLOAK_USER="developer"
KEYCLOAK_PASSWORD="developer"
KEYCLOAK_ADMIN="admin"
KEYCLOAK_ADMIN_PASSWORD="admin"
KC_DB="postgres"
KC_DB_URL="jdbc:postgresql://database/keycloak"
# KC_HOSTNAME_FRONTEND_URL=""
# KC_HOSTNAME_ADMIN_URL=""

Usage Instructions

  1. Run docker compose up to run the containers in interactive mode.

    1. Upon first run your db-data directory should fill up with files and directories.
  2. Run docker compose up -d to run your containers in the background.
  3. Run docker-compose down --rmi all to completely cleanup all containers.
  4. Modify the command command: ["start-dev"] to start keycloak in the other modes. This is necessary as the entrypoint isn't specific enough.

It may be useful to create an optimized Keycloak image, but that wasn't necessary for my purposes.

  1. Modify the image section image: quay.io/keycloak/keycloak:21.0.1 to keycloak-custom:latest to use the custom image.

    1. We can publish this image to our own registry if we wanted but this is fine for now. I doubt we'll want to use this outside of production.
  2. To build the optimized Keycloak image independently, run the following: docker build -t keycloak-custom:latest ..

Resources
